The AEC241 is a Dual Output Potentiometer / Resistance Signal Transmitter calibrated and manufactured within our high impact polycarbonate enclosure and is suitable for combinations of Potentiometer Input & process Voltage or Current Outputs.
Furthermore the AMELEC standard 10 year warranty applies to this instrument.
If you require RFI protection, we provide an add-on option to the latest standard IEC61000-4-3.
- Input is the nominal 5K ohms potentiometer 2 or 3 wire, other values are available on request
- Standard output is a 4-20mA signal, other ranges are available on request
Environmental Condition
Mounting/Dimensions
Environmental Condition
Storage Temperature: -20°C to +70°C
Operating Ambient: 0°C to +55°C
Relative Humidity: 5% to 95% RH
Mounting/Dimensions
Enclosure: 22.5w x 75h x 105d mm
Din Rail (TS35) or Surface by corner fixing holes
